KHA CITY 12

  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Black aluminum reflector provides full-cutoff, no glare design, and precision optical control (COMFORT options).
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type III light distribution.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Steel ground base plate included for bollards.
  • - Anchor bolts available for bollards (ordered separately).
  • - Concrete installation fixing rods available (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
KHA CITY 12 TYPE III

KHA CITY 12 TYPE III

Optic | Asymmetric Medium
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Steel ground base plate included for bollards.
  • - Anchor bolts available for bollards (ordered separately).
  • - Concrete installation fixing rods available (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
076481 LED 20 W 120/277 V 80 3000 - - 2800 1474 L80 B10 80000 Download

Documentation: KHA CITY 12 TYPE III - 076481
076482 LED 20 W 120/277 V 80 3000 - - 2800 1474 L80 B10 80000 Download

Documentation: KHA CITY 12 TYPE III - 076482
076484 LED 20 W 120/277 V 80 4000 - - 2900 1538 L80 B10 80000 Download

Documentation: KHA CITY 12 TYPE III - 076484
076485 LED 20 W 120/277 V 80 4000 - - 2900 1538 L80 B10 80000 Download

Documentation: KHA CITY 12 TYPE III - 076485

Sources

LED 20 W
KHA CITY 12 TYPE V

KHA CITY 12 TYPE V

Optic | Circular Extra-Wide
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Black aluminum reflector provides full-cutoff, no glare design, and precision optical control (COMFORT options).
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Steel ground base plate included for bollards.
  • - Anchor bolts available for bollards (ordered separately).
  • - Concrete installation fixing rods available (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
076475 LED 23 W 120/277 V 80 3000 - - 3220 2313 L80 B10 220000 Download

Documentation: KHA CITY 12 TYPE V - 076475
076476 LED 23 W 120/277 V 80 3000 - - 3220 2313 L80 B10 220000 Download

Documentation: KHA CITY 12 TYPE V - 076476
076478 LED 23 W 120/277 V 80 4000 - - 3335 2434 L80 B10 220000 Download

Documentation: KHA CITY 12 TYPE V - 076478
076479 LED 23 W 120/277 V 80 4000 - - 3335 2434 L80 B10 220000 Download

Documentation: KHA CITY 12 TYPE V - 076479

Sources

LED 23 W
KHA CITY COMFORT 12 TYPE III

KHA CITY COMFORT 12 TYPE III

Optic | Asymmetric Medium
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Steel ground base plate included for bollards.
  • - Anchor bolts available for bollards (ordered separately).
  • - Concrete installation fixing rods available (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
076491 LED 20 W 120/277 V 80 3000 - - 2800 1290 L80 B10 80000 Download

Documentation: KHA CITY COMFORT 12 TYPE III - 076491
076492 LED 20 W 120/277 V 80 3000 - - 2800 1290 L80 B10 80000 Download

Documentation: KHA CITY COMFORT 12 TYPE III - 076492
076493 LED 20 W 120/277 V 80 4000 - - 2900 1345 L80 B10 80000 Download

Documentation: KHA CITY COMFORT 12 TYPE III - 076493
076494 LED 20 W 120/277 V 80 4000 - - 2900 1345 L80 B10 80000 Download

Documentation: KHA CITY COMFORT 12 TYPE III - 076494

Sources

LED 20 W
KHA CITY COMFORT 12 TYPE V

KHA CITY COMFORT 12 TYPE V

Optic | Circular Extra-Wide
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Black aluminum reflector provides full-cutoff, no glare design, and precision optical control (COMFORT options).
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Steel ground base plate included for bollards.
  • - Anchor bolts available for bollards (ordered separately).
  • - Concrete installation fixing rods available (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
076487 LED 23 W 120/277 V 80 3000 - - 3220 1955 L80 B10 220000 Download

Documentation: KHA CITY COMFORT 12 TYPE V - 076487
076488 LED 23 W 120/277 V 80 3000 - - 3220 1955 L80 B10 220000 Download

Documentation: KHA CITY COMFORT 12 TYPE V - 076488
076489 LED 23 W 120/277 V 80 4000 - - 3335 2056 L80 B10 220000 Download

Documentation: KHA CITY COMFORT 12 TYPE V - 076489
076490 LED 23 W 120/277 V 80 4000 - - 3335 2056 L80 B10 220000 Download

Documentation: KHA CITY COMFORT 12 TYPE V - 076490

Sources

LED 23 W
KHA CITY MARINE 12 TYPE III

KHA CITY MARINE 12 TYPE III

Optic | Asymmetric Medium
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Steel ground base plate included for bollards.
  • - Anchor bolts available for bollards (ordered separately).
  • - Concrete installation fixing rods available (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
076483 LED 20 W 120/277 V 80 3000 - - 2800 1474 L80 B10 80000 Download

Documentation: KHA CITY MARINE 12 TYPE III - 076483
076486 LED 20 W 120/277 V 80 4000 - - 2900 1538 L80 B10 80000 Download

Documentation: KHA CITY MARINE 12 TYPE III - 076486

Sources

LED 20 W
KHA CITY MARINE 12 TYPE V

KHA CITY MARINE 12 TYPE V

Optic | Circular Extra-Wide
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Black aluminum reflector provides full-cutoff, no glare design, and precision optical control (COMFORT options).
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Steel ground base plate included for bollards.
  • - Anchor bolts available for bollards (ordered separately).
  • - Concrete installation fixing rods available (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
076477 LED 23 W 120/277 V 80 3000 - - 3220 2313 L80 B10 220000 Download

Documentation: KHA CITY MARINE 12 TYPE V - 076477
076480 LED 23 W 120/277 V 80 4000 - - 3335 2434 L80 B10 220000 Download

Documentation: KHA CITY MARINE 12 TYPE V - 076480

Sources

LED 23 W

Product Family

KHA CITY 24 KHA CITY 24
Open filters Close filters
Welcome!
You can enter the PERFORMANCE iN LIGHTING world by consulting the sites available for each country, differentiated by language, services, and catalogue offerings. Choose the country or geographical area you are in.
Confirm USA/Canada (us) Change country
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
