Q-LIGHT

Pathway bollard series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) aluminum extruded post.
- Copper-free (<1%) precision die-cast aluminum housing and top cap.
- Clear UV-stabilized, high-impact resistant diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
- Type V light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
- Pre-wired factory sealed cable for external electrical connection included.
- Steel ground base plate included for bollards.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
- 5-year warranty.

Optic | Symmetric Wide

Pathway bollard series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) aluminum extruded post.
- Copper-free (<1%) precision die-cast aluminum housing and top cap.
- Clear UV-stabilized, high-impact resistant diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
- Type V light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
- Pre-wired factory sealed cable for external electrical connection included.
- Steel ground base plate included for bollards.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070345	LED	14 W	120/277 V	80	3000	-	-	1944	1032	L90	B10	36000	Documentation: Q-LIGHT - 070345
070346	LED	14 W	120/277 V	80	4000	-	-	2088	1166	L90	B10	36000	Documentation: Q-LIGHT - 070346
070347	LED	14 W	120/277 V	80	3000	-	-	1944	1032	L90	B10	36000	Documentation: Q-LIGHT - 070347
070348	LED	14 W	120/277 V	80	4000	-	-	2088	1166	L90	B10	36000	Documentation: Q-LIGHT - 070348
072345	LED	21 W	120/277 V	80	3000	-	-	2780	1480	L90	B10	36000	Documentation: Q-LIGHT - 072345
072346	LED	21 W	120/277 V	80	4000	-	-	2980	1662	L90	B10	36000	Documentation: Q-LIGHT - 072346
072347	LED	21 W	120/277 V	80	3000	-	-	2780	1480	L90	B10	36000	Documentation: Q-LIGHT - 072347
072348	LED	21 W	120/277 V	80	4000	-	-	2980	1662	L90	B10	36000	Documentation: Q-LIGHT - 072348

Sources

LED	14 W
LED	21 W
