AMON MINI TYPE V

Description

• Lighting column series. Fixtures consist of:
• - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
• - Robust copper-free (<1%) extruded aluminum column profile and copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, top cap, and inspection access door.
• - Custom molded, anti-aging gasket(s).
• - Stainless steel external hardware.
• - Extra-clear, tempered, silk-screened, flat glass diffuser.
• - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
• - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
• - Type V light distribution.
• - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
• - Steel ground base plate included for bollards.
• - Base heavy-duty cover, anchor bolts, and direct-burial support available for AMON MINI / MAXI (ordered separately).
• - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
• - 5-year warranty.
• - Product meets Buy American Act (BAA) requirements within ARRA.
